Effects of Different Straw Returning Depths on Soil Greenhouse Gas Emission and Maize Yield
ZHU XiaoQing, AN Jing, MA Ling, CHEN SongLing, LI JiaQi, ZOU HongTao,, ZHANG YuLongCollege of Land and Environment, Shenyang Agricultural University/Northeast Key Laboratory of Conservation and Improvement of Cultivated (Shenyang) Ministry of Agriculture and Rural Affairs/ National Engineering Laboratory of Efficient Utilization of Soil and Fertilizer Resources, Shenyang 110866
Abstract 【Objective】 Straw returning is an important technical means to improve soil fertility, increase soil organic matter and improve soil structure. However, previous studies have shown that straw returning can accelerate the emission of greenhouse gases in soil and increase greenhouse effect. Through the study of greenhouse gas emission characteristics and maize yield of farmland soil under different straw returning depths, the optimum returning depths were determined in this study, in order to provide scientific basis for rational utilization of straw, increase crop yield and realize sustainable agricultural development. 【Method】 In the field micro-plot experiment, maize was used as the test crop, and four returning depths were set up, which were 0-10 cm (T1), 10-20 cm (T2), 20-30 cm (T3) and 30-40 cm (T4), respectively. At the same time, the non-returning treatment was used as the control (CK), with a total of five treatments. Static box-gas chromatography was used to determine the greenhouse gases (CO2, CH4, N2O) emission characteristics under different returning depths in whole maize growing season, and yield and yield components at maturity were measured. 【Result】 (1) During the whole maize growing season, both CO2 and N2O showed emission, but CH4 showed absorption. The cumulative emission of CO2 was the highest under T3 treatment, which increased by 28.6% significantly compared with CK. The increase rate of cumulative emission of CO2 under T4 treatment was the least, which was significantly increased by 17.1% compared with CK (P<0.05), but the difference between T1 and T4 treatment was not significant; the cumulative emission of N2O was the highest under T2 treatment. Compared with CK, the cumulative amount of N2O increased significantly by 111.3%, the increase rate under T4 treatment was the least, and the CK increased significantly by 12.8% (P<0.05). However, CH4 showed absorption, and the absorption capacity of CH4 in farmland soil was reduced after straw returning; the absorption capacity was CK treatment>T4 treatment>T1 treatment>T3 treatment>T2 treatment, and there were significant differences between treatments and CK (P<0.05). (2) Compared with the control, the yield of maize in each treatment increased significantly, and the yield increased by 5.6%-20.8% (P<0.05). However, there were no significant difference in ear length, ear diameter and grain number between treatments. When the straw returned to 30-40 cm, the yield was the highest, which increased by 20.76% than that under CK, and it indicated that straw returning had an important effect on improving soil fertility and increasing crop yield. (3) According to the comprehensive greenhouse gas effect (GWP) and greenhouse gas emission intensity (GHGI), on the scale of 100 years, GWP showed T2 treatment>T3 treatment>T1 treatment>T4 treatment>CK treatment, while GHGI showed T2 treatment>T3 treatment>T1 treatment>CK treatment>T4 treatment. Compared with CK, all treatments increased the comprehensive greenhouse gas effect, while T4 treatment reduced greenhouse gas emission intensity in maize season, indicating that straw returning to 30-40 cm could alleviate the global warming trend to a certain extent. 【Conclusion】 Straw returning could increase CO2 and N2O emissions significantly, but increase the absorption capacity of CH4. The straw returning to 30-40 cm could reduce the global warming potential and the intensity of greenhouse gas emissions, and increase the maize yield significantly. Therefore, in order to simultaneously achieve higher maize yield and lower greenhouse gas emission intensity, straw returning to 30-40 cm was a more reasonable way of soil improvement and fertilization. Keywords:greenhouse gases;straw returning depths;emission flux;maize yield;global warming potential
PDF (526KB)元数据多维度评价相关文章导出EndNote|Ris|Bibtex收藏本文 本文引用格式 朱晓晴, 安晶, 马玲, 陈松岭, 李嘉琦, 邹洪涛, 张玉龙. 秸秆还田深度对土壤温室气体排放及玉米产量的影响[J]. 中国农业科学, 2020, 53(5): 977-989 doi:10.3864/j.issn.0578-1752.2020.05.010 ZHU XiaoQing, AN Jing, MA Ling, CHEN SongLing, LI JiaQi, ZOU HongTao, ZHANG YuLong. Effects of Different Straw Returning Depths on Soil Greenhouse Gas Emission and Maize Yield[J]. Scientia Acricultura Sinica, 2020, 53(5): 977-989 doi:10.3864/j.issn.0578-1752.2020.05.010
玉米生长季不同还田深度下综合增温潜势(GWP)和温室气体排放强度(GHGI)的估算结果如表5所示。由表5可知,在所有处理中T2处理对农田综合增温潜势的贡献最大,与CK相比,TI、T2、T3和T4处理综合增温潜势分别增加了23.8%、120.3%、54.3%和12.3%,T4处理的固碳效应值最大,为0.54 t CO2-eq·hm-2;在各处理的产量具有明显差异的情况下,温室气体排放强度(GHGI)也呈现出与GWP不同的变化趋势。秸秆不同还田深度下温室气体排放强度为T2处理>T3处理>T1处理>CK处理>T4处理,T4处理的GHGI值最小,为410.87 kg·CO2-eq·t-1,低于其他处理,但是产量最高。
Table 5 表5 表5秸秆不同还田深度下的综合净增温潜势(GWP)和气体排放强度(GHGI) Table 5Changes of GWP and GHGI from the corn field under different depths of straw returning
PAN GX, GAOM, HU GH, WEI QP, YANG XG, ZHANG WZ, ZHOU GS, ZOU JW . Impacts of climate change on agricultural production of China Journal of Agro-Environment Science, 2011,30(9):1698-1706. (in Chinese) [本文引用: 1]
SMITH DM, CUSACKS, COLMAN AW, FOLLAND CK, HARRIS GR, MURPHY JM . Improved surface temperature prediction for the coming decade from a global climate model , 2007,317(5839):796-799. [本文引用: 1]
HEJ, LI HF, FANGL, HUX, KONG WC . Influence of straw application on agricultural greenhouse gas emissions in China Chinese Agricultural Science Bulletin, 2011(20):246-250. (in Chinese) [本文引用: 1]
BI YY, GAO CY, WANG YJ, LI BY . Estimation of straw resources in China Transactions of the Chinese Society Agricultural Engineering, 2009,25(12):211-217. (in Chinese) [本文引用: 1]
ZHAOJ, LIY, RANW, ZHANG RF, SHENB, SHEN QR . Effects of organic manure partial substitution for chemical fertilizer on crop yield and soil microbiome in a rice-wheat cropping system Journal of Nanjing Agricultural University, 2016,39(4):594-602. (in Chinese) [本文引用: 1]
LU WT, JIA ZK, ZHANGP, WANGW, HOU XQ, YANG BP, LI YP . Effects of straw returning on soil labile organic carbon and enzyme activity in semi-arid areas of southern Ningxia, China Journal of Agro-Environment Science, 2011,30(3):522-528. (in Chinese) [本文引用: 1]
LI CF, HOU ZK, ZHANG ZS, CAO CG, WU HY, MEI JA, ZHAI ZB, ZHANG CD, WEI TX, LIU SQ . Effects of rape residue mulch on greenhouse gas emissions and carbon sequestration from no-tillage rice fields Journal of Agro-Environment Science, 2011,30(11):2362-2367. (in Chinese) [本文引用: 1]
MENGM, Lü CW, LI YE, QIN XB, WAN YF, GAO QZ . Effect of biochar on CH4 and N2O emissions from early rice field in South China Chinese Journal of Agrometeorology, 2013,34(4):396-402. (in Chinese) [本文引用: 1]
JACINTHE PA, LALR, KIMBLE JM . Carbon budget and seasonal carbon dioxide emission from a central Ohio Luvisol as influenced by wheat residue amendment , 2002,67(2):147-157. [本文引用: 1]
ZHANG QZ, WU WL, WANG MX, ZHOU ZR, CHEN SF . The effects of crop residue amendment and N rate on soil respiration Acta Ecologica Sinica, 2005,25(11):2883-2887. (in Chinese) [本文引用: 1]
QIANG XC, YUAN HL, GAO WS . Effect of crop-residue incorporation on soil CO2 emission and soil microbial biomass Chinese Journal of Applied Ecology, 2004,15(3):469-472. (in Chinese) [本文引用: 1]
SONG QL, WANG QR, WANGQ, FANG YJ, SUNY, ZENG XN, LAI YC . Effects of corn straw mulching on carbon emission of black soil Agricultural Science of Jiangsu,2017,45(13):219-222. (in Chinese) [本文引用: 1]
WUJ . Effects of different straw return modes and straw biochar application on greenhouse gas emission and soil carbon sequestration in agriculture [D]. Nanjing: Nanjing Agricultural University, 2014. ( in Chinese) [本文引用: 1]
BHATTACHARYYAP, ROY KS, NEOGIS, ADHYA TK, RAO KS, MANNA MC . Effects of rice straw and nitrogen fertilization on greenhouse gas emissions and carbon storage in tropical flooded soil planted with rice , 2012,124:119-130. [本文引用: 1]
ZOU GY, ZHANG FS, CHEN XP, JU XT, LIU XJ, PAN JR . Effect of straw addition on denitrification in upland soil Review of China Agricultural Science and Technology, 2001(6):47-50. (in Chinese) [本文引用: 1]
WANG GL, HAO MD, CHEN DL . Effect of stubble incorporation and nitrogen fertilization on denitrification and nitrous oxide emission in an irrigated maize soil Plant Nutrition and Fertilizer Science, 2006(6):840-844. (in Chinese) [本文引用: 1]
CHENC, BAO YX, LüQ, TANGQ . Simulation of nitrous oxide emission under different straw retention depths based on denitrification-decomposition model Anhui Agricultural Sciences, 2018,46(14):64-67, 74. (in Chinese) [本文引用: 1]
YAN CP, ZHANG YM, HU CS, DONG WX, WANG YY, LI XX, QIN SP . Greenhouse gas exchange and comprehensive global warming potential under different wheat-maize rotation patterns Chinese Journal of Eco-Agriculture, 2016,24(6):704-715. (in Chinese) [本文引用: 1]
ZHANGD, PANG, WUG, KIBUE GW, LIL, ZHANGX, ZHENGJ, ZHENGJ, CHENGK, JOSEPHS . Biochar helps enhance maize productivity and reduce greenhouse gas emissions under balanced fertilization in a rained low fertility inceptisol , 2015,142:106. [本文引用: 1]
YANG SY, YANP, MA YH, DAI JW, HAN HB, WANG DL, FANG HY . Effects on emissions of soil greenhouse gas by fertilizing to winter wheat Ecology and Environmental Sciences . 2010,19(7):1642-1645. (in Chinese) [本文引用: 1]
TIAN SZ, NING TY, LI ZJ, WANGY, LI HJ, ZHONG WL . Effect of CH4 uptake flux under different tillage systems in wheat field in the North China Plain Acta Ecologica Sinica, 2010,30(2):541-548. (in Chinese) [本文引用: 1]
MENG SX, LIU CY, ZHENG XH, LIANG WG, HU RG . Effects of the applied amount of wheat straw on methane, carbon dioxide, nitrous oxide,and nitric oxide fluxes of a bare soil in south Shanxi Climatic and Environmental Research, 2012,17(4):504-514. (in Chinese) [本文引用: 1]
YANGX, LANY, MENGJ, CHEN WF . Effects of different stover-incorporation ways on CO2 emission in dryland brown soil and soil carbon pool management index Chinese Journal of Ecology, 2015,34(3):805-809. (in Chinese) [本文引用: 1]
XIE YQ, ZHANG JF, JIANG HM, YANG JC, DENG SH, LIX, GUO JM, LI LL, LIUX, ZHOU GY . Effects of different fertilization practices on greenhouse gas emissions from paddy soil Journal of Agro-Environment Science, 2015,34(3):578-584. (in Chinese) [本文引用: 1]
ZHENG XH, WANGR. Surface Observation Method of Carbon and Nitrogen Exchange Flux Between Terrestrial Ecosystem and Atmosphere: Protocols for Chamber-based Manual Measurement of CH4 and N2O Fluxes from Terrestrial Ecosystems. Beijing: China Meteorological Press, 2017: 59-61. (in Chinese) [本文引用: 1]
WANGK, ZHENG XH, PIHLATIEM, VESALAT, LIU CY, HAAPANALAS, MAMMARELLAI, RANNIK, LIU HZ . Comparison between static chamber and tunable diode laser-based eddy covariance techniques for measuring nitrous oxide fluxes from a cotton field , 2013,9(19):171-172. [本文引用: 1]
IPCC. . Cambridge: Cambridge University Press, 2013. [本文引用: 1]
XIONG ZQ, ZHANG XX . Key role of efficient nitrogen application in low carbon agriculture Journal of Plant Nutrition and Fertilizer, 2017,23(6):1433-1440. (in Chinese) [本文引用: 1]
ZHOUJ, LIB, XIAL, FANC, XIONGZ . Organic-substitute strategies reduced carbon and reactive nitrogen footprints and gained net ecosystem economic benefit for intensive vegetable production , 2019,225:984-994. [本文引用: 1]
HUANGY, ZHANGW, SUN WJ, ZHENG XH . Net primary production of Chinese croplands from 1950 to 1999 , 2007,17(3):692-701. [本文引用: 1]
ZHANGX, FANC, MAY, LIUY, LIL, ZHOUQ, XIONGZ . Two approaches for net ecosystem carbon budgets and soil carbon sequestration in a rice-wheat rotation system in China , 2014,100(3):301-313. [本文引用: 1]
SONG LN, ZHANG YM, HU CX, ZHANG XY, DONG WX, WANG YY, QIN SP . Comprehensive analysis of emissions and global warming effects of greenhouse gases in winter-wheat fields in the high-yield agro-region of North China Plain Chinese Journal of Eco-Agriculture, 2013,21(3):297-307. (in Chinese) [本文引用: 1]
LI XH, ZHU ZL, DONG HY, YANG LP, GUO HH . Characteristics of greenhouse gas emissions from the wheat fields with different returning methods of maize straws Journal of Agricultural Resources and Environment, 2016,33(2):176-181. (in Chinese) [本文引用: 1]
SINGH SN, KULSHRESHTHAK, AGNIHOTRIS . Seasonal dynamics of methane emission from wetlands , 2000,2(1):39-46. [本文引用: 1]
YU JG, LI HX, HUF, SHENY . Effects of straw application and earthworm inoculation on soil particulate organic carbon and mineral-associated organic carbon Ecology and Environment,2006(3):606-610. (in Chinese) [本文引用: 1]
SUN XX, MOU CC, SHI LY, CHENGW, LIUX, WU YX, FENG DJ . Methane emission from forested swamps in Xiaoxing’an mountains, Northeastern China Chinese Journal of Plant Ecology, 2009,33(3):535-545. (in Chinese) [本文引用: 1]
LI ZG, ZHANG RH, LAI DM, YAN ZY, TIAN CY . CH4 and N2O fluxes from cotton fields different in farming practices in northwestern China Acta Pedologica Sinica, 2012,49(5):925-934. (in Chinese) [本文引用: 1]
SUN XX, MOU CC, MIN CL, LIUX, WU YX, FENG DJ, SHI LY, CHENGW . Diurnal variation in methane fluxes from wetlands in Xiao Xing'an Mountains Northeast China Journal of Northeast Forestry University, 2009,37(11):92-95. (in Chinese) [本文引用: 1]
GAO DC, ZHANGL, LIUQ, RONG XM, ZHANG YP, TIANC . Effects of biochar on CO2, CH4, N2O emission and its environmental benefits in dryland soil Acta Ecologica Sinica, 2015,35(11):3615-3624. (in Chinese) [本文引用: 1]
ZHAI YY, CHENG YX, CHANG SH, HOU FJ . Mechanism of greenhouse gas emission from agro-ecosystem soil in arid regions Chinese Agricultural Science Bulletin,2015,31(9):231-236. (in Chinese) [本文引用: 1]
ZHANGJ . The exchanges of greenhouse gases and effect factors in winter wheat/green onion interplanting system [D]. Beijing: Chinese Academy of Agricultural Sciences, 2012. ( in Chinese) [本文引用: 1]
BREMNER JM . Sources of nitrous oxide in soils , 1997,49(1/3):7-16. [本文引用: 1]
ZOU GY, ZHANG FS, CHEN XP, JU XT, LIU XJ, PAN JR . Effect of straw addition on denitrification in upland soil Review of China Agricultural Science and Technology, 2001,3(6):47-50. (in Chinese) [本文引用: 1]
SEY BK, WHALEN JK, GREGORICH EG, ROCHETTEP, CUE RI . Carbon dioxide and nitrous oxide content in soils under corn and soybean , 2008,72(4):931. [本文引用: 1]
WANG SP, ZHOU GS, JIANGY, LIU XY . Effect of incorporating corn residues into soil on nitrogen transformation in soil-plant ecosystem Chinese Journal of Applied Ecology, 2004,15(3):449-452. (in Chinese) [本文引用: 1]
GUO TF, LIANG GQ, ZHOUW, LIU DH, WANG XB, SUN JW, LI SL, HUC . Effect of fertilizer management on greenhouse gas emission and nutrient status in paddy soil Journal of Plant Nutrition and Fertilizers,2016,22(2):337-345. (in Chinese) [本文引用: 1]
LI CF, HOU ZK, ZHANG ZS, CAO CG, WU HY, MEI JA, ZHAI ZB, ZHANG CD, WEI TX, LIU SQ . Effects of rape residue mulch on greenhouse gas emissions and carbon sequestration from no-tillage rice fields Journal of Agro-Environment Science, 2011,30(11):2362-2367. (in Chinese) [本文引用: 1]
XIE LY, YE DD, ZHANGH, GUO LP . Review of influence factors on greenhouse gases emission from upland soils and relevant adjustment practices Chinese Journal of Agrometeorology, 2011,32(4):481-487. (in Chinese) [本文引用: 1]
Lü YJ, YU HY, YAO FY, CAO YJ, WEI WW, WANG LC, WANG YJ . Effects of soil straw return and nitrogen on spring maize yield, greenhouse gas emission and soil enzyme activity in black soils Chinese Journal of Eco-Agriculture, 2016,24(11):1456-1463. (in Chinese) [本文引用: 1]
HUANGY, BI SY, ZOU HT, DOUS . Effect of straw deep returning on corn root system and yield Journal of Maize Sciences, 2013(5):109-112. (in Chinese) [本文引用: 1]
WANG SN, ZOU HT, ZHANG YL, YUN, ZHANG YL, FAN QF, HUANGY . Effects of deeply and concentratedly returned straw on soil main properties and corn root system Agricultural Research in the Arid Areas, 2015(3):68-71, 78. (in Chinese) [本文引用: 1]
